Sleep Deprivation Chamber Walking Model
Chamber Specifications
Clear rectangular chamber
Chamber dimensions:
Outside: 16.0"L x 11"W x 15"H
Inside Living Space: 9"L x 8"W x 8"H
Custom dimensions available
Power: 220V single phase, 50Hz frequency, 200W total power
Weight: 25kg
Key Features
Motor
Operating speed: 1-100 m/min
Speed control range: 0-100 m/min
Precision: 0.01 m/min
Noise level: <30dB (extremely quiet)
Measurement accuracy: cm measurement, <±0.1%
Touch Screen
Capacitive HD LCD screen with high response speed and easy operation
Configuration Control
Configurable parameters: Total time, scheduled start, rotation period, periodic break, rotation mode
Rotation modes: Clockwise, counterclockwise, alternate, and random
Day light control: User can define the day light period
Automated start and stop
One session duration: Up to 900 hours
Schedule: For example, if start = 3 am, total time = 5 hours in the schedule setting, the device will automatically start at 3 am and stop at 8 am every day
Configuration Upload
Configurations are saved on device and can be uploaded to PC
Data browsing and printing: The system automatically saves 50 sets of experimental data; experimenter can browse any experimental data, export and print to computer for post-processing
Automatic data storage, COM interface and computer connection
